10m3 Liquid Waste Disposal Truck 12m3 Septic Tank Pumping Trucks Made by Dongfeng 190HP Cu Mmins Engine

Basic Info

Model NO.	FYEQ5160
After-sales Service	7X24 Hours Online After Sales Service
Warranty	One Year
Certification	ISO9000, CCC, TS16949, EPA, EEC, RoHS
Emission Standard	Euro 3/4/5/6
Payload	10-16ton
Transmission Type	Manual
Fuel	Diesel
Tank Volume	10000L-12000L
Drive Wheel	4x2
Hoesrpower	170-210HP
Condition	New
Vacuum Pump	Chinese Brand Weilong or Italy Brand Jurop / Moro
Pressure Gauge	Chiese Brand or Italy Import
Manhole	with
Boom	with
Transport Package	Nuked, Shipping by Container
Specification	10000L Septic tank pump truck
Trademark	FUYA
Origin	Hubei, China
HS Code	8703224001
Production Capacity	5000 PCS Per Year

Product Description

HUEBEI FUYA VEHICLE CO.,LTD

I. Details of 10m3 Liquid waste disposal truck 12m3 septic tank pumping trucks made by Dongfeng 190HP cu mmins engine

Function:

(1)Septic tank truck (also called liquid waste disposal truck ,sewage sucking truck ,liquid waste sucking truck ,sewage suction tank truck ,fecal suction car ,septic tanker vacuum truck ,septic removal truck ,liquid sewage truck ,septic tanker ,septic tank pumping ,septic tank cleaner ,sewage removal ,vacuum truck ,septic tanker ,sewage pump ,fecal sludge truck ) is used to colloet ,transport and discharge dirty water ,sludge ,septic ,etc. Such liquid stuff .It is suitable for cleaning the septic tank ,cesspool ,guily ,etc. It is widely used in environment and sanitation filed .(2)Accessory of sewage suction function :Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.(3)vacuum tank capacity ranges from 3,000 Liters to 22,000 liters

Features:a. Cylinder vacuum tank can be lifted hydraulically to 40-45 degree.Rear door can be opened and closed hydraulically. b. Adopt EU vacuum pump (Italy brand) or equivalent China top brand double vacuum pumps,super powerful,highly efficient. c. Pump can be operated by a hydraulic motor or by an auxiliary engine. d. Overfill system with music horn is equipped ,preventing the vacuum pump damage from sewage water into vacuum pump when the tank is full. e. Nice shape ,rational structure,durable and long service life
II. Technical data of 10m3 Liquid waste disposal truck 12m3 septic tank pumping trucks made by Dongfeng 190HP cu mmins engine

Vacuum Pump Small 10000L Fecal Suction Sewage Truck

Vehicle parameters
Vehicle name	Fecal suction truck
Overall dimensions	8010×2462×3300mm	Curb weight	7670kg
Rated load weight	8135 kg	Total weight	15990kg

Chassis parameters
Chassis model		EQ1168KJ	Chassis brand	DONGFENG
Maximum speed		90km/h	Wheel base	4500mm
Front axle/ rear axle		5T/10T
Chassis Manufacturer		Dongfeng Motor Company
Cab	Configuration	allowable 3 passengers , cabin can be turned forward. With air conditioner
	Color	Blue,other color is optional
Engine	Model	B190 33 / 140KW
	Emission	Euro 3
	Rated power	190hp
	Displacement	5900ml
	Manufacturer	Dongfeng Engine
Tire	Size	10.00-20/6
	Number	6+1 nos
Drive form	4X2
Transmissions	8 gearbox gear
Steering device	Power assisted steering
Steering wheel	Left hand drive

III. STRUCTURE OF SEPTIC TANK TRUCK / FECAL SUCTION TRUCK IV. MAIN PARTS OF SEPTIC TANK TRUCK / FECAL SUCTION TRUCK

V. VACUUM SEWAGE SUCTION TRUCK WORKMANSHOP



VI. SHIPPING:RORO/BULK VESSEL/CONTAINER
RORO: The truck is driven to the ship inside directly and fixed well. It can protect the truck being rusty and broken during shipping. BULK: The truck is lifted by crane then put on the vessel deck. This model is much cheaper.CONTAINER: The truck is put into the container. This model is used for small model trucks


VIII. ABOUT US

HUBEI FUYA VEHICLE CO.,LTD ,which is appointed by the Development and Reform Commission of China, is a professional manufacturer of special automobiles for landscaping, petrochemical, and environment cleanness, etc. Our company has independent export authority, with good technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation, we have attracted a lot of customer from all over the world.

Main products: 1. LPG Tank Truck Trailer/ Fuel Tanker Truck2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker3. Truck with crane / Truck mounted crane4. Dump Truck / Tipper Truck/Side Tipper/End Tipper5. Fire Fighting Truck / Fire Truck / Fire Vehicle6. Concrete Mixer Truck / Pump Truck7. Van truck / Blasting equipment transporter/ Refrigerated truck8. Fecal suction truck / Sewage suction truck, 9. Cement Powder Tank truck/ Bulk cement truck10. High-altitude operation truck, 11. Garbage truck, garbage compactor truck, Hook Lift Garbage Truck12. High Pressure Cleaning Truck13. Sweeper Truck / Vacuum Sweeper Truck14. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

Main info as below:l More than 10 years' experience as a manufacturerl CCC, ISO, BV, ASME certificationl Perfect after-sale servicel Trucks covering more than 50 countries and regionsl 300 kinds of trucks and trailersl 100 Senior welder and 15 senior engineers l Good cooperation with 30% regular customersl Annual production value topped 240,000,000 US dollars per year

Our advantage:a.Competitive Price and Excellent Qualityb.More than 10 years' experience as a manufacturerc.CCC, ISO, BV certificationd.Perfect after-sale servicee.Customized products available with us,f.Export covering More than 50 countries and regionsg.Annual production value topped 1500, 000, 000 RMB (240, 000, 000 US dollars) per yearFAQ1
Q: What's the brand of your truck? A: Our brand is FUYA, First it is the biggest truck manufacture in China, our products cover all series such as tractor truck, tipper truck, cargo truck, and other special trucks.2.
Q: How can we trust your company? A: We are the official authority company by Chengli Special Automobile And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us.We are your reliable partner. 3.
Q: Can u provide the ISO9001 certificate or some others related? A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed. 4.
Q: How about warranty item? A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.5. Payment: 30%-50 deposit after order confirmation, balance should be paid before delivery. All by T/T, L/C.6. Our warranty: (1). One year quality guarantee for three key parts: Axles, engine, transmission. (2). Other spare part could be supplied by OEM at cost prices. (3). Regularly callback to know the vehicle's working status. (4). The overseas engineers are always ready to deal with unexpected needs. Any more need or comment, please let us know that.Welcome to visit our factory at any time!
